Phase number 2

Steps / per revolution 400

Step angle accuracy ±5%

Shaft load (000 hours at 1000 RPM)

Axial load 25 N (5.6 Lbs.) thrust

65 N (15 Lbs.) pull

Radial load 30 N (6.5 Lbs.) acting point at the midpoint of the flat wire

IP rating 40

Certification UL Recognized File E465363, RoHS

Operating environment temperature -20°C to +50°C

Insulation class B, 130°C

Insulation resistance 100 MegOhms
