Number of phases 3

Steps / per revolution 300

Step angle accuracy ±5%

Shaft load (000 hours at 1000 RPM)

Axial load 40 N (9 Lbs.) thrust

130 N (30 Lbs.) pull

Radial load 70 N (15.5 Lbs.) acting point at the midpoint of the flat wire

IP rating 40

Certification RoHS

Operating environment temperature -20°C to +50°C

Insulation class B, 130°C
