Phase number 3

Steps / per circle 300

Step angle accuracy ±5%

Axis load (000 hours at 1000 RPM)

Axial load 25 N (5.6 Lbs.) thrust

65 N (15 Lbs.) tension

Radial load 29 N (6.5 Lbs.) acting point at the midpoint of the flat wire

IP rating 40

Certification RoHS

Operating environment temperature -20°C to +50°C

Insulation class B, 130°C
