Number of phases 2

Steps / per revolution 200

Step angle accuracy ±5%

Shaft load (000 hours at 1000 RPM)

Axial load 250 N (56 Lbs.) thrust

Radial load 450 N (100 Lbs.) acting at the midpoint of the tooth slot

IP rating 40

Certification UL Recognized File E465363, RoHS

Operating environment temperature -20°C to +40°C

Insulation class B, 130°C
