Number of steps 2

Steps / per revolution 200

Step angle accuracy ±5%

Shaft load (000 hours at 1000 RPM)

Axial load 65 N (15 Lbs.) thrust

155 N (35 Lbs.) tension

Radial load 220 N (50 Lbs.) acting point at the midpoint of the flat wire

IP rating 40

Certification UL Recognized File E465363, RoHS

Operating environment temperature -20°C to +50°C

Insulation class B, 130°C
