Phase number 2

Steps / per circle 200

Step angle accuracy ±5%

Axial load (000 hours at 1000 RPM)

Axial load 6 N (1.3 Lbs.) thrust

25 N (5.6 Lbs.) tension

Radial load 18 N (4 Lbs.) acting point at the top of the output shaft

IP rating 40

Certification RoHS

Operating environment temperature -20°C to +50°C

Insulation class B, 130°C

Insulation resistance 100 MegOhms
